2-room DIY mini split
Indoor units: small (9,000 BTU / 9K) + small (9K) · outdoor unit 18,000 BTU
Make it your systemChoose your line sets
Each indoor unit needs one line set running to the outdoor unit. Measure from where the indoor unit will hang to where the outdoor unit will sit.
Protection planOptional · pays labor, part shipping and refrigerant on warranty repairs
If a part the warranty covers fails, the plan pays the technician, part shipping and refrigerant.
Free curbside shipping
Why order from Status
Shipping expected to begin by November 1, 2026
Pre-orders go out in order; tracking arrives by email the day yours leaves the warehouse.
Designed for DIY installation
Pre-charged Quick Connect line sets simplify installation. Follow the manufacturer’s instructions and check local requirements before you start.
Real HVAC techs on the phone
24/7 — before and after your install.
What’s included
Outdoor unit · 18,000 BTUOne outdoor unit for all 2 rooms
Indoor units · 9,000 BTU (9K) × 22 units · small rooms (up to 400 sq ft each)
Remotes & app2 remotes, one per indoor unit · ConnectLife app with Amazon Alexa and Google Assistant
Line sets · selected separatelyNot included in the base price. Select a length for each indoor unit above, or choose your own.
About your mini split
- 2 rooms (9K + 9K indoor units)
- Coverage: up to 400 sq ft per room
- SEER2 up to 23 (cooling efficiency rating — higher is better) · Inverter heat pump
- Heats down to -13°F outdoor
- Pre-charged Quick Connect line sets — install kit included per room
Accessories
Technical specifications
System
- Refrigerant
- R454B
- Cooling range
- 14 °F to 109 °F outdoor
- Heating range
- −13 °F to 75 °F outdoor
- Wi-Fi
- Built into each indoor unit, 2.4 GHz
- App & voice control
- ConnectLife app, Amazon Alexa, Google Assistant
Each indoor unit comes with a 25 ft communication cable attached. If its line set run is longer than 25 ft, that indoor unit needs a longer communication cable (not included).
18K outdoor unit
- Nominal capacity
- 18,000 Btu/h
- SEER2
- 23
- Power supply
- 230 V, single phase
- Breaker (MOP)
- 25 A
- Min. circuit ampacity
- 21 A
- Shipping carton
- 39" × 17.7" × 28.7"
- Shipping weight
- 112 lb
9K indoor unit × 2
- Coverage
- up to 400 sq ft
- Rated cooling
- 9,000 Btu/h
- Line set
- 1/4" × 3/8" pre-charged Quick Connect
- Communication cable
- 25 ft, attached
- Dimensions
- 35" W × 10.75" H × 8.75" D
- Unit weight
- 18.75 lb
- Shipping carton
- 36.6" × 15" × 11.2"
- Shipping weight
- 23 lb
Manuals & downloads
- Owner’s manualInstallation, wiring, operation and troubleshooting
- App manualConnectLife app setup, Amazon Alexa and Google Assistant
- Remote control manualButtons, modes and timers
Shipping & warranty
When it arrives
It comes on a pallet to the curb, not inside — the outdoor unit is the heavy box, so have a helper ready. Transit takes 4–10 days once it ships.
Warranty
8-year limited warranty on the compressor and parts, handled by Status directly. Installing it yourself doesn't affect coverage: the warranty applies to your own installation done per the instructions and local codes — no HVAC contractor required. Register your system once it's installed. The warranty covers parts only; a protection plan adds the technician, part shipping and refrigerant for 2 or 5 years.
